Smart helmet
Dedicated for best quality innovations
Smart helmet
IP66 5G smart safety helmet integrating HD video, real-time positioning, and attitude sensors for intelligent frontline emergency rescue operations.
The 5G smart safety helmet integrates a high-definition camera, multi-mode positioning, and sensor modules, enabling real-time audio and video transmission and remote command and dispatch via a 5G network. It features a built-in three-axis accelerometer and gyroscope, making it suitable for complex scenarios such as power line inspection, construction, and emergency rescue. Its IP66 waterproof and dustproof design, combined with a lightweight PC shell, provides workers with dual protection and intelligent management capabilities.
High Hardware Integration: Integrates a high-definition camera, multi-mode positioning module, and various types of sensors to achieve integrated sensing and data acquisition.
5G High-Speed Transmission and Remote Command: Utilizes 5G networks for real-time audio and video transmission, supporting remote command and dispatch with strong real-time communication capabilities.
Attitude and Safety Monitoring: Built-in three-axis accelerometer and gyroscope for sensing and monitoring personnel posture and movement.
Multi-Scenario Adaptability: Suitable for complex operational scenarios such as power line inspection, construction, and emergency rescue.
High Protection and Durability: Adopts an IP66 waterproof and dustproof design, combined with a lightweight PC shell, providing excellent protective performance.
Dual Safety and Management Guarantee: Combines physical protection for personnel with intelligent operation management functions, providing comprehensive support for frontline workers.
| Name | Specification |
| General Configuration
| Camera: 21 MP, 1080P resolution; lightweight design, no disassembly required; instant field-of-view display
|
| Dimensions: 294 mm × 228.5 mm × 153.5 mm (L × W × H)
| |
| Operating System: Android 11
| |
| Communication & Positioning
| LTE-FDD Bands: B1 / B3 / B5 / B7 / B8 / B20 / B28 LTE-TDD Bands: B34 / B38 / B39 / B40 / B41 WCDMA Bands: B1 / B2 / B5 / B8 5G Bands: N1 / N3 / N28 / N41 / N77 / N78 / N79 GSM Bands: B2 / B3 / B5 / B8
|
| Positioning: BeiDou, GPS
| |
| WIFI：（IEEE802.11b/g/n，2.4G; 5G） | |
| SIM: Dual Nano SIM cards; dual SIM slots with AI voice switching
| |
| Weight
| ≤ 650 g (including standard internal components and electronics)
|
| Storage
| Up to 512 GB supported Dual TF card slots (supports two TF cards)
|
| Protection Rating
| Material: ABS Ingress Protection: IP66
|
| Communication Antennas
| 1 × Main antenna 1 × LTE diversity antenna 1 × Wi-Fi & Bluetooth combined antenna 1 × GPS ceramic antenna 1 × Near-field sensing antenna
|
| Battery | 5000 mAh, 3.7 V removable polymer battery · （Supports charging indication, battery level display, and detachable charging ) |
| Micro USB | Micro USB 5pin ,supports charging and data transmission
|
| 4PIN，Supports magnetic charging
| |
| Sensors
| Supported (standard configuration): Gyroscope sensor Light sensor Barometer Near-field sensing Security/encryption chip
|
| Audio
| Type: Surface-mount Configuration: Main microphone Secondary microphone (noise reduction) Voice microphone Built-in dual speakers (supports earpiece mode) |
What are your core products?
A: Our core products include:
Portable Command & Dispatch Consoles
Integrated Triple-Screen Mobile Command Terminals
Emergency Communication System Solutions
Multi-Terminal Collaborative Command Platforms
What are the core advantages of your products?
A:
Rapid Deployment (Out-of-the-box readiness)
Multi-Network Convergence (4G/5G/Satellite/Private Networks)
Multi-Source Video Access (Drones, Body-worn cameras, etc.)
ntelligent Dispatch & Coordinated Command
