UAV Carried Ad-hoc Networks
Low-latency, vehicle-mounted ad-hoc mesh network system providing stable real-time data transmission in high-speed mobile emergency rescue environments.
UAV carried ad-hoc network equipment is a core component of on-site emergency command and communication solutions and can be mounted on drones. It features the ability to collect and transmit on-site images, voice, and data, and is suitable for applications such as mobile coverage, multi-hop relay transmission, and long-distance coverage. It is characterized by its small size, light weight, and high integration, making it easy to carry and deploy quickly.
Core Equipment Positioning: As the core equipment of the on-site emergency command and communication solution, it plays a critical role as a communication hub and data bearer.
Airborne Adaptation: Designed specifically for UAV platforms, it can be stably mounted on UAVs and adapted to aerial mobile
communication scenarios.
Multi-Service Integrated Transmission: It has the comprehensive acquisition and transmission capabilities of on-site images, voice, and data, meeting the full range of communication needs of emergency command.
Flexible Networking and Transmission Capabilities: Supports mobile coverage, relay multi-hop transmission, and long-distance coverage, with flexible networking methods and a wide communication coverage area.
Lightweight and Highly Integrated Design: The equipment is small in size, lightweight, and highly integrated, making it easy to carry, deploy quickly, and use on UAVs.
Strong Scenario Adaptability: Suitable for various complex emergency environments, enabling aerial mobile communication and long-distance relay transmission support.
| Name | Specification |
| RF parameters | Operating frequency band: 1.4GHz (1420MHz~1530MHz) |
| Number of channels: 2 | |
| Transmission frequency: Maximum transmission power 33dBm | |
| Sensitivity: -97dBm/20MHz (accessible) | |
| Performance parameters | Carrier bandwidth: 5MHz/10MHz/20MHz |
| Number of network devices: Supports a maximum of 32 nodes in a network. | |
| Single-hop latency: One-way latency less than 25ms@20MHz | |
| Data rate: Peak rate 80Mbps | |
| Interfaces | 1*RJ45, 1*Data connector, 1*BD, 2*1.4G auxiliary antennas |
| Power | External 79200mAh battery, can be used to power drones. |
| Size | 270*205*89.5mm |
| Weight | Less than 2.2kg (excluding accessories) |
| Obedient temperature | Working temperature ：-20℃~55℃ Storage temperature ：-30℃~65℃ |
