x1800（Lightweight Portable Command Box）
Ultra-lightweight 8.3kg three-screen portable command box with IP66 protection, built for rapid localized tactical deployment in harsh, disconnected environments.
This product is a portable command box designed and developed for special working environments. It integrates many functional modules and interfaces (industrial control computer, video conferencing terminal, camera, triple display screen, touch control screen, speaker, microphone, lithium battery and other basic equipment). The outer shell of the device is made of PP material, and the whole machine provides IP66 protection. The internal main structure is made of 3K aerospace-grade carbon fiber material and aviation aluminum alloy, and is manufactured by CNC process. The alloy surface of the interface board is anodized, which effectively reduces weight and greatly improves durability and protection of the equipment.
One-touch intelligent control: Features an industry-exclusive one-touch touchpad system, allowing for one-click changes to device settings without navigating menus.
Highly integrated localized deployment: Integrates dual industrial control units, supporting localized deployment of the command platform, enabling on-site command even in the event of a three-way power outage.
Ultra-lightweight and portable design: The industry’s lightest, thinnest, and smallest three-screen portable command box, with a single industrial control unit weighing only 8.3 kg, facilitating easy portability.
Full-scenario multi-link communication: Includes Ethernet ports, WIFI, and 5G modules, allowing connection to external satellite portable stations and self-organizing network devices.
| Name | Specification |
| Box size | 514mm*422mm*154mm |
| Weight | 12.5KG+/-0.5KG(Customized products, weight subject to actual measurement） |
| Power Interface | AC 220V/50HZ |
| USB Interface | 2 *USB 2.0 |
| Video Interface | Video Input:1 *HDMI Video Output:2 *HDMI |
| Audio Interface | Support MIC-IN*1、LINE -IN*1、LINE-OUT*1 |
| SIM card slot | 1*SIM card slot |
| Protection level | IP66 |
| Ambient temperature | Working temperature: -10℃ ~ 45℃ Storage temperature: -25℃ ~ 60℃ |
| Screen size | 15.6 inch screen, 1920*1080 resolution |
| 4G/5G router(choose one) | 5G full network compatibility,backward compatible with 2G,3G,and 4G |
| Information processor | Processor: Intel Core i7 8650U quad-core, 8-thread (i7 10700T/i7 11700T optional RAM 16GB(expandable to 96GB) Ethernet port: 3RJ47 10/100/1000Mbps ports Storage 512GB SSD (1TB/2TB optional) |
| Battery | Battery standard voltage: DC 12.6V Battery capacity:200Wh |
| Video conferencing terminal | Optional configurations include: Huawei BOX 310, Huawei BAR310, Huawei box200, ZTE312T,etc.
|
